Graphical User Interface (GUI) Controlled Mobile Robot

Authors

  • M. H. Zulkefli Department of Electrical Engineering Technology, Faculty of Engineering Technology, Universiti Teknikal Malaysia Melaka, Malaysia
  • K. A. Mohd Annuar Department of Electrical Engineering Technology, Faculty of Engineering Technology, Universiti Teknikal Malaysia Melaka, Malaysia
  • S. H. Johari Department of Electrical Engineering Technology, Faculty of Engineering Technology, Universiti Teknikal Malaysia Melaka, Malaysia
  • M. R. Mohamad Sapiee Department of Electrical Engineering Technology, Faculty of Engineering Technology, Universiti Teknikal Malaysia Melaka, Malaysia
  • S. Ahmad Department of Electrical Engineering Technology, Faculty of Engineering Technology, Universiti Teknikal Malaysia Melaka, Malaysia

Keywords:

GUI, Monitoring system, Wireless, Image feedback, Mobile robot

Abstract

The advanced design and development of robotic technology in producing multi task are increasingly. In this paper presents about designing and developing mobile robot model that can be controlled using Graphical User Interface (GUI) via wireless protocol. This paper focuses on the control mobile robot by using the GUI as navigation control and the user can get a view an image and real time video on visual basic software. To address the problem of sired based control, XBee wireless communication circuit was used in mobile robot through a computer command. The development of this mobile robot consists of a chassis, a graphical user interface (GUI), XBee module, DC gear motor, camera, track wheels and microcontroller type PIC18F4550. Differential driving method using L298 circuit was used to control movement of the robot. In mechanical design, the wheel track has been used instead of conventional wheels to enable the robot to travel through different types of surfaces or rough terrain. In addition, wireless cameras was attached to the robot as a system of monitoring function. Finally, the robot will be designed to control wireless remote control that can control robots. Wireless remote control allows the user of an environment that is unsafe or dangerous device and evades wires or cables interfere with the movement of the robot.

Downloads

Download data is not yet available.

Downloads

Published

2023-10-18

How to Cite

M. H. Zulkefli, K. A. Mohd Annuar, S. H. Johari, M. R. Mohamad Sapiee, & S. Ahmad. (2023). Graphical User Interface (GUI) Controlled Mobile Robot. Journal of Advanced Research in Computing and Applications, 1(1), 42–49. Retrieved from https://www.akademiabaru.com/submit/index.php/arca/article/view/5026
